The TP-DCDC-1248GD-HP DC to DC converters offered by Tycon Power Systems are a low cost and high reliability solution for those requiring 35W 802.3af/at Power Over Ethernet voltage from a 10-15VDC battery system. They have an integrated Gigabit Compatible 802.3af/at POE injector to apply the regulated 56VDC to the CAT5 Ethernet cable. They accept data-in to a shielded RJ45 Jack and provide data-out and POE power on the shielded RJ45 output jack. They work by supplying power on the unused Ethernet pins 4,5(V+) and 7,8(V-). They have various protections for surge, short circuit and overload. The units have power output of 35W. Features Input Voltage 18-36VDC or 24-72VDC POE Output voltage 56VDC High Power 30W Non-compliant POE Dual DC Inputs for connecting 2 power sources Integrated POE Inserter Low self consumption power Short Circuit, Over Current and Over Voltage Protection High Temperature Operation Applications 24V and 48V Battery Systems Wireless Access Points and Client Devices IP Phone and Security Camera Systems

TP-DCDC-1248GD-HP 10-15VDC IN 56VDC OUT, 35W DC to DC Conv

SKU:
TP-DCDC-1248GD-HP
Availability:
In stock Items usually ship within 24 hours, see our stock policy.
$79.95
(No reviews yet)
Weight:
1.75 LBS
Current Stock:
Adding to cart… The item has been added
Description

The TP-DCDC-1248GD-HP DC to DC converters offered by Tycon Power Systems are a low cost and high reliability solution for those requiring 35W 802.3af/at Power Over Ethernet voltage from a 10-15VDC battery system.

They have an integrated Gigabit Compatible 802.3af/at POE injector to apply the regulated 56VDC to the CAT5 Ethernet cable.

They accept data-in to a shielded RJ45 Jack and provide data-out and POE power on the shielded RJ45 output jack.

They work by supplying power on the unused Ethernet pins 4,5(V+) and 7,8(V-).

They have various protections for surge, short circuit and overload. The units have power output of 35W.

Features

  • Input Voltage 18-36VDC or 24-72VDC
  • POE Output voltage 56VDC
  • High Power 30W
  • Non-compliant POE
  • Dual DC Inputs for connecting 2 power sources
  • Integrated POE Inserter
  • Low self consumption power
  • Short Circuit, Over Current and Over Voltage Protection
  • High Temperature Operation

Applications

  • 24V and 48V Battery Systems
  • Wireless Access Points and Client Devices
  • IP Phone and Security Camera Systems
