MTI Wireless Edge Ltd. MTI 16dBi 65° 4x4 MU-MIMO 4.9-5.9GHz
MTI Wireless Edge
$149.00
** SPECIFICALLY DESIGNED FOR USE WITH THE MIMOSA A5c ** ELECTRICAL
- REGULATORY COMPLIANCE RoHS, CE 0682
- FREQUENCY RANGE 4.9-5.9 GHz
- GAIN 16 dBi ± 0.5 dB
- VSWR 1.5 : 1 (typ), 1.7:1 (max)
- POLARIZATION Double Dual Linear ± 45°
- -3dB ELEVATION BEAMWIDTH 7º (typ)
- -3 dB AZIMUTH BEAMWIDTH 65° (typ)
- ELEVATION SIDELOBE LEVEL -12 dB (typ.)
- F/B RATIO -40 dB (typ)
- CROSS POLARIZATION -15 dB (typ)
- PORT TO PORT ISOLATION 20dB (typ)
MECHANICAL
- DIMENSIONS (LxWxD) 371 x 371 x 40mm (max)
- CONNECTOR 4 x N-Type Female
- WEIGHT 2 Kg (max)
- MOUNTING KIT MT-120018
- RADOME MATERIAL Plastic
- BASE PLATE MATERIAL Aluminum with chemical conversion coating
- POWER 6W (max)
- INPUT IMPEDANCE 50 (ohm)
- LIGHTNING PROTECTION DC Grounded
MOUNTING
- Antenna Mounting Bracket Included
